16 pcs in one box,price for box, color mixed

16 pcs in one box,price for box, color mixed

CT4221

Advanced Hartman Type Auto Refractometer
High speed image acquisition and image identification.
8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

High speed image acquisition and image identification.

8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

3D Intelligent measurement achieves auto focus.

Built-in thermal printer has auto paper cutting function.



Auto Refractometer and Refracto-Keratometer is one high precision instrument of objective measuring the patient’s eyes with unique optical system inside and accurate imaging analyzing and processing in Hartman technology. It’s mainly used to measure the patient’s diopter, including sphere power, cylinder power, optical axis, pupil distance and corneal curvature, to provide reference data for eyes’ treating and eyeglasses choice. The measurement result can be displayed on screen or printed out on the paper.



Specifications

VD Range: 0.0, 12.0, 13.75 and 15.0

Sphere Range: -20.00D ~ +20.00D (VD=12, 0.01 ,0.06, 0.12, 0.25 Increments)

Cylinder Range:0.00D ~ ±10.00D (0.06, 0.12, 0.25 Increments)

Axis:1 degree ~ 180 degree (1 degree Increment)

Cylinder Symbol:-, +, mixed

PD Range:10mm~86mm

Pupil Distance:2.00mm~8.00mm

Mini Pupil Size:2.0mm

Curvature Radius:5.0mm~10.0mm (0.01mm Increments)

Refractive Power:33.00D~67.00D

Cylindrical Power:0.00D~-15.00D (0.06D/0.12D/0.25D Increments)

Axis:1° ~180°

Target:Auto Fog

Average Measurement Time:<0.5 second

Max Brightness:<30uw (Safety Assure)

Date Save:10 Groups Left/Right Eye

Printer:57mm Width, Auto Cutting

Power:AC 100~250V, 50/60Hz

Gross Weight:26.5kgs

Net Weight:22kgs

Standard Acessories:User’s Manual (1)
Dustproof Cover (1)
Lens Dustproof Piston (1)
Model Eye (1)
Power Line (1)
Chinrest Paper (1)
Cleaning Cloth (1)
Printing Paper (1)
Fuse (2)
Chinrest Pin (2)

Advanced Hartman Type Auto Refractometer
High speed image acquisition and image identification.
8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

High speed image acquisition and image identification.

8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

3D Intelligent measurement achieves auto focus.

Built-in thermal printer has auto paper cutting function.



Auto Refractometer and Refracto-Keratometer is one high precision instrument of objective measuring the patient’s eyes with unique optical system inside and accurate imaging analyzing and processing in Hartman technology. It’s mainly used to measure the patient’s diopter, including sphere power, cylinder power, optical axis, pupil distance and corneal curvature, to provide reference data for eyes’ treating and eyeglasses choice. The measurement result can be displayed on screen or printed out on the paper.



Specifications

VD Range: 0.0, 12.0, 13.75 and 15.0

Sphere Range: -20.00D ~ +20.00D (VD=12, 0.01 ,0.06, 0.12, 0.25 Increments)

Cylinder Range:0.00D ~ ±10.00D (0.06, 0.12, 0.25 Increments)

Axis:1 degree ~ 180 degree (1 degree Increment)

Cylinder Symbol:-, +, mixed

PD Range:10mm~86mm

Pupil Distance:2.00mm~8.00mm

Mini Pupil Size:2.0mm

Curvature Radius:5.0mm~10.0mm (0.01mm Increments)

Refractive Power:33.00D~67.00D

Cylindrical Power:0.00D~-15.00D (0.06D/0.12D/0.25D Increments)

Axis:1° ~180°

Target:Auto Fog

Average Measurement Time:<0.5 second

Max Brightness:<30uw (Safety Assure)

Date Save:10 Groups Left/Right Eye

Printer:57mm Width, Auto Cutting

Power:AC 100~250V, 50/60Hz

Gross Weight:26.5kgs

Net Weight:22kgs

Standard Acessories:User’s Manual (1)
Dustproof Cover (1)
Lens Dustproof Piston (1)
Model Eye (1)
Power Line (1)
Chinrest Paper (1)
Cleaning Cloth (1)
Printing Paper (1)
Fuse (2)
Chinrest Pin (2)

CT4711B

PD, nose pad height, axis, temple angle and leg length are all adjustable.

3pcs lenses could be inserted at the front. 2pcs lenses could be inserted at the back side.

Material: Nylon, Aluminum & Titanium

PD: 48 to 90mm

DPR300

ALFA9500

Advanced 3D tracking and auto focus Auto Refractometer
High speed image acquisition and image identification.
10.4-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

High speed image acquisition and image identification.

10.4-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

3D Intelligent measurement achieves auto focus.

Built-in thermal printer has auto paper cutting function.



Auto Refractometer and Refracto-Keratometer is one high precision instrument of objective measuring the patient’s eyes with unique optical system inside and accurate imaging analyzing and processing in Hartman technology. It’s mainly used to measure the patient’s diopter, including sphere power, cylinder power, optical axis, pupil distance and corneal curvature, to provide reference data for eyes’ treating and eyeglasses choice. The measurement result can be displayed on screen or printed out on the paper.



Specifications

VD Range: 0.0, 12.0, 13.75 and 15.0

Sphere Range: -25.00D ~ +20.00D (VD=12, 0.01 ,0.06, 0.12, 0.25 Increments)

Cylinder Range:-8.00D ~ +8.00D (0.06, 0.12, 0.25 Increments)

Axis:1 degree ~ 180 degree (1 degree Increment)

Cylinder Symbol:-, +, mixed

PD Range:5mm~90mm

Pupil Distance:2.00mm~8.00mm

Mini Pupil Size:2.0mm

Curvature Radius:5.0mm~10.0mm (0.01mm Increments)

Refractive Power:33.75D~67.50D

Cylindrical Power:0.00D~-15.00D (0.06D/0.12D/0.25D Increments)

Axis:1° ~180°

Target:Auto Fog

Average Measurement Time:<0.5 second

Max Brightness:<30uw (Safety Assure)

Date Save:10 Groups Left/Right Eye

Printer:57mm Width, Auto Cutting

Power:AC 100~250V, 50/60Hz

Gross Weight:26.5kgs

Net Weight:22kgs

Standard Acessories:User’s Manual (1)
Dustproof Cover (1)
Lens Dustproof Piston (1)
Model Eye (1)
Power Line (1)
Chinrest Paper (1)
Cleaning Cloth (1)
Printing Paper (1)
Fuse (2)
Chinrest Pin (2)

CM100

Specifications:

Installation Distance: 0.15-0.2M phoropter center line to mirror (equivalent to the standard 5 meters optometry distance)

Number of Charts: 33 (Distance), 7 (Near)


Chart Type:

Tumbling E, Alphabet, Numbers, Children charts, Cross Cylinder, Astigmatism Clock Dial, Cross Grid, Fixation Spot, Stereo, Red & Green Panel, Worth 4-dot, Horizontal & Vertical Coincidence, Schober etc.

Charts Control: Control Panel of AP-800 auto phoropter

Charts Size: 210(W)*80(H)MM

Output interfaces: USB, LAN, RS232, which can realize interconnection with other equipment, such as AP-800 auto phoropter, FA-100/FA-100K auto refractometer and computer.

Wireless Connection: WIFI and Bluetooth are available.

Light source: LCD backlight, LED fill light

Voltage: AC100-240V, 60Hz/50Hz

Power: 75VA

Dimension:450(W)*555(H)*470(D)MM
