CT4113

CT1720

Venus5

Parallel Type, Galilean System
Stereoscopic binocular fusion
Can upgrade to teaching slit lamp and digital slit lamp

Magnification Changer: Revolving Drum
LS-4: 6x, 10x, 16x, 25x, 40x, 5-step magnification

Light Source System Upgrade
Warm LED light source, suitable for eye tissue for 20,000 hours
Use PMW to ensure the brightness of light source stable
Continuous illumination control makes it more convenient to operate

ALFA9100

Advanced Hartman Type Auto Refractometer
High speed image acquisition and image identification.
8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

High speed image acquisition and image identification.

8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

3D Intelligent measurement achieves auto focus.

Built-in thermal printer has auto paper cutting function.



Auto Refractometer and Refracto-Keratometer is one high precision instrument of objective measuring the patient’s eyes with unique optical system inside and accurate imaging analyzing and processing in Hartman technology. It’s mainly used to measure the patient’s diopter, including sphere power, cylinder power, optical axis, pupil distance and corneal curvature, to provide reference data for eyes’ treating and eyeglasses choice. The measurement result can be displayed on screen or printed out on the paper.



Specifications

VD Range: 0.0, 12.0, 13.75 and 15.0

Sphere Range: -20.00D ~ +20.00D (VD=12, 0.01 ,0.06, 0.12, 0.25 Increments)

Cylinder Range:0.00D ~ ±10.00D (0.06, 0.12, 0.25 Increments)

Axis:1 degree ~ 180 degree (1 degree Increment)

Cylinder Symbol:-, +, mixed

PD Range:10mm~86mm

Pupil Distance:2.00mm~8.00mm

Mini Pupil Size:2.0mm

Curvature Radius:5.0mm~10.0mm (0.01mm Increments)

Refractive Power:33.00D~67.00D

Cylindrical Power:0.00D~-15.00D (0.06D/0.12D/0.25D Increments)

Axis:1° ~180°

Target:Auto Fog

Average Measurement Time:<0.5 second

Max Brightness:<30uw (Safety Assure)

Date Save:10 Groups Left/Right Eye

Printer:57mm Width, Auto Cutting

Power:AC 100~250V, 50/60Hz

Gross Weight:26.5kgs

Net Weight:22kgs

Standard Acessories:User’s Manual (1)
Dustproof Cover (1)
Lens Dustproof Piston (1)
Model Eye (1)
Power Line (1)
Chinrest Paper (1)
Cleaning Cloth (1)
Printing Paper (1)
Fuse (2)
Chinrest Pin (2)

CT60N

CT2204 Fixed PD Trial Frame

10 different PD sizes are optional

7 different colors



Specification

Single or set are both available.

The PD range: 52mm, 54mm, 56mm, 58mm, 60mm, 62mm, 64mm, 66mm, 68mm, 70mm

Standard Set Package: 8pcs/box (56mm to 70mm)

Net weight: 40g/pc

Color: grey, blue, black, green, yellow, red, purple

PD, nose pad height, axis, temple angle and leg length are all adjustable.

3pcs lenses could be inserted at the front. 2pcs lenses could be inserted at the back side.

Material: Nylon, Aluminum & Titanium

PD: 48 to 90mm

Metal material
About 60g net weight
PD range: 48 to 80MM

CT5203N without U-shape switch

Big size, durable diamond grinding wheel

Protective cover above the wheel

Safe railing is easy to control the wheel rotation

Automatic water supply system

CT5508

CT1955

Lifting range:460~ 600mm
Rotation angle of chair:±60°
Backrest obliquity:90°~135°
Max. loading:150kgs
Lifting height for pillow:≤150mm
Power:140W
Voltage:AC110V/60HZ or AC220V/50HZ
Fuse:5A 250V
Weight:60kgs
Size:700mmx900mmx 1400mm
Poder:140 W
Voltaje:AC110V/60HZ o AC220V/50HZ
Fusible:5A 250V
Peso:60kgs
Tamaño:700mmx900mmx 1400mm

CT5514

CT4711B

CT4714

CT4718

CT4724

AP800

SPECIFICATIONS

Sphere 0D～+16.75D，0D～-19D ,step 0.25 D

cylinder -8.75 D～+8.75 D，step 0.25 D

Axis 0°～180°，step 1°

Prism 0～20Δ，step 0.1Δ

Prism base 0°～360°，step 1°

PD 48mm～80mm，step 1mm

Distance 350mm～700mm

VD 12mm、13.75mm、16mm、18mm、20mm

Auxiliary Lens PH, Binoculus（￠ =1.0mm）

RMV/RMH
RL(Right eye)、GL（Left eye）
Polaroid（Right eye 135°/45°），（Left eye 45°/135°）
Prism（Right 6△ BU ，10△BU），（Left 3 △ BD, 10 △BI）
Cross Cylinder Lens(±0.50D Axis=90°)
PD Lens

Rotary Prism 0~20 △（0.1 △ /0.5 △）

Cross Cylinder Lens ±0.25D

Retinoscope +1.50D(67cm)，+2.00D(50cm)

AP head size

360mm×80mm×26mm 2kg

Power supply

100V~240V 60/50HZ

Projection distance 3m to 6m
Projection scale 30x (at the distance of 5m)
Charts 39 selections
Masking function No mask, Horizontal line mask, Vertical line mask, Single letter mask
Filtering function Red/Green filter
Chart changeover speed Average of 0.2 seconds or less
Chart size 336 (W)*225(H)mm (at the distance of 5m)
lamp LED
Weight 5kgs
Dimensions Main body:208(W)*287(H)*346(L)mm
Control board: 67(W)*200(L)*21(H)mm
Power source AC 100-240V, 50/60 Hz, 36W
