Venus5AOS

Venus5SVI

SL1

Venus3

YZ30R

CT4704

CT4704-3

Specifications:
0.00D, -0.25D, -0.50D, -0.75D, -1.00D, -1.25D, -1.50D, -1.75D, -2.00D, -2.50D,
-3.00D, -3.50D, -4.00D, -5.00D, -6.00D, -7.00D, -8.00D, -10.0D, -12.0D, -14.0D, -16.0D, -18.0D
+0.25D, +0.50D, +0.75D, +1.00D, +1.25D, +1.50D, +1.75D, +2.00D, +2.25D, +2.50D,
+2.75D, +3.00D, +3.25D, +3.50D, +3.75D, +4.00D, +4.50D, +5.00D, +5.50D, +6.00D, +6.50D,
+7.00D, +8.00D, +9.00D, +10.0D, +11.0D, +12.0D, +13.0D, +14.0D, +16.0D, +18.0D, +20.0D, +22.0D

CT1720

Venus5

Parallel Type, Galilean System
Stereoscopic binocular fusion
Can upgrade to teaching slit lamp and digital slit lamp

Magnification Changer: Revolving Drum
LS-4: 6x, 10x, 16x, 25x, 40x, 5-step magnification

Light Source System Upgrade
Warm LED light source, suitable for eye tissue for 20,000 hours
Use PMW to ensure the brightness of light source stable
Continuous illumination control makes it more convenient to operate

ALFA9100

Advanced Hartman Type Auto Refractometer
High speed image acquisition and image identification.
8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

High speed image acquisition and image identification.

8-inch TFT touch screen, supports 360 degree rotation and 180 degree flip.

3D Intelligent measurement achieves auto focus.

Built-in thermal printer has auto paper cutting function.



Auto Refractometer and Refracto-Keratometer is one high precision instrument of objective measuring the patient’s eyes with unique optical system inside and accurate imaging analyzing and processing in Hartman technology. It’s mainly used to measure the patient’s diopter, including sphere power, cylinder power, optical axis, pupil distance and corneal curvature, to provide reference data for eyes’ treating and eyeglasses choice. The measurement result can be displayed on screen or printed out on the paper.



Specifications

VD Range: 0.0, 12.0, 13.75 and 15.0

Sphere Range: -20.00D ~ +20.00D (VD=12, 0.01 ,0.06, 0.12, 0.25 Increments)

Cylinder Range:0.00D ~ ±10.00D (0.06, 0.12, 0.25 Increments)

Axis:1 degree ~ 180 degree (1 degree Increment)

Cylinder Symbol:-, +, mixed

PD Range:10mm~86mm

Pupil Distance:2.00mm~8.00mm

Mini Pupil Size:2.0mm

Curvature Radius:5.0mm~10.0mm (0.01mm Increments)

Refractive Power:33.00D~67.00D

Cylindrical Power:0.00D~-15.00D (0.06D/0.12D/0.25D Increments)

Axis:1° ~180°

Target:Auto Fog

Average Measurement Time:<0.5 second

Max Brightness:<30uw (Safety Assure)

Date Save:10 Groups Left/Right Eye

Printer:57mm Width, Auto Cutting

Power:AC 100~250V, 50/60Hz

Gross Weight:26.5kgs

Net Weight:22kgs

Standard Acessories:User’s Manual (1)
Dustproof Cover (1)
Lens Dustproof Piston (1)
Model Eye (1)
Power Line (1)
Chinrest Paper (1)
Cleaning Cloth (1)
Printing Paper (1)
Fuse (2)
Chinrest Pin (2)

CT60N

PD, nose pad height, axis, temple angle and leg length are all adjustable.

3pcs lenses could be inserted at the front. 2pcs lenses could be inserted at the back side.

Material: Nylon, Aluminum & Titanium

PD: 48 to 90mm

Metal material
About 60g net weight
PD range: 48 to 80MM
